3 Illustrated parts catalog
Service tag
When ordering parts or requesting information, provide the computer serial number and model
number provided on the service tag. It is necessary to remove the battery to obtain these numbers.
See
Battery for battery removal instructions.
Item Description Function
(1) Product name This is the product name affixed to the front of
the computer.
(2) Serial number (s/n) This is an alphanumeric identifier that is unique to
each product.
(3) Part number/Product number (p/n) This number provides specific information about the
product's hardware components. The part number
helps a service technician to determine what
components and parts are needed.
14 Chapter 3 Illustrated parts catalog
