Metric U.S.
Contrast ratio 200:1 (typical)
Brightness 200 nits (typical)
Pixel resolution
Pitch 0.197 × 0.197 mm
Format 1366 × 768
Configuration RGB vertical stripe
Backlight LED
Character display 80 × 25
Total power consumption 3.46 W
Viewing angle ±65° horizontal, ±50° vertical (typical)
Hard drive specifications
1-TB* 750-GB** 640-GB**
Dimensions
Height 9.5 mm 9.5 mm 9.5 mm
Length 100.2 mm 100.2 mm 100.2 mm
Width 69.9 mm 69.9 mm 69.9 mm
Weight 98 g 98 g 98 g
Interface type SATA SATA SATA
Transfer rate
Synchronous (maximum) 97 MB/sec 97 MB/sec 106 MB/sec
Security ATA security ATA security ATA security
Seek times (typical read, including setting)
Single track 2.0 ms 2.0 ms 1.5 ms
Average (read/write) 12/16 ms 12/16 ms 11/13 ms
Maximum 21 ms 21 ms 24 ms
Logical blocks 1,953,525,168 1,465,149,168 1,250,263,728
Disk rotational speed 5400 rpm 7200 and 5400 rpm 7200 rpm
Operating temperature 0°C to 60°C (32°F to 140°F)
*1 TB = 1 trillion bytes when referring to hard drive storage capacity. Actual accessible capacity is less.
**1 GB = 1 billion bytes when referring to hard drive storage capacity. Actual accessible capacity is less.
NOTE: Certain restrictions and exclusions apply. Contact technical support for details.
Hard drive specifications 75
