Keyboard
NOTE: All keyboard spare part kits include backlit keyboards, and include keyboard cables and
keyboard backlight cables.
Description Spare part number
For use only in Canada 698084-DB1
For use only in Latin America 698084-161
For use only in the United States 698084-001
Before removing the keyboard, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery), and then remove the following components:
a. Service cover (see
Hard drive)
b. Optical drive (see
Optical drive)
c. WLAN module (see
WLAN module)
Component replacement procedures 41
