RTC battery
Description Spare part number
RTC battery 676654-001
Before removing the RTC battery, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery), and then remove the following components:
5. Remove the service cover (see
Hard drive).
Remove the RTC battery:
▲
Use a thin, non-conductive tool (1) to remove the RTC battery (2) from the socket on the
system board.
Reverse this procedure to install the RTC battery. When installing the RTC battery, make sure the “+”
sign faces up.
40 Chapter 4 Removal and replacement procedures
