3. Remove the speakers (3) from the computer.
To install the speakers, reverse this procedure.
Touchpad
To remove the touchpad, use this procedure and illustration.
Table 5-4
Touchpad description and part number
Description Spare part number
Touchpad, flint gray N85230-001
Touchpad, galactic blue N85231-001
Touchpad cable (available in the Cable Kit) N85232-001
Touchpad bracket N91997-001
Before removing the touchpad, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 28).
2. Remove the bottom cover (see Bottom cover on page 28).
3. Remove the battery (see Battery on page 29).
Remove the touchpad:
32
Chapter 5 Removal and replacement procedures for authorized service provider parts
