2. Remove the heat sink (3).
3. Each time the heat sink is removed, thoroughly clean and replace the thermal material from the
surface of the heat sink. Replacement thermal material is included with the heat sink and system
board spare part kits.
Reverse this procedure to install the heat sink.
System board
To remove the system board, use these procedures and illustrations.
Table 5-9
System board descriptions and part numbers
Description Spare part number
System board (includes the processor, replacement thermal material, and the Chrome operating
system)
NOTE: The system board bracket is available in the Bracket Kit as spare part number N85234-001.
Intel N200 processor, 16 GB system memory, 128 GB UFS memory N84321-001
Intel N200 processor, 16 GB system memory, 128 GB UFS memory (WWAN models) N84322-001
System board 39
