Using the ProCurve Web Browser Interface
Web Configuration
Using the ProCurve Web
Browser Interface
Web – Click Ports, Statistics.
Trunk Membership
This page allows you to create static trunks. Trunking allows you to assign
physical links to one logical link (trunk) that functions as a single, higher-
speed link providing dramatically increased bandwidth. This capability
applies to connections between backbone devices as well as to connections
in other network areas where traffic bottlenecks exist.
The Membership Table has one row for each port and a column for each trunk,
plus an additional column for ports that are not members of a trunk. Each row
contains radio buttons that are used to indicate which trunk (if any) the port
belongs to.
Port Trunking Support ProCurve 1700-8 ProCurve 1700-24
Ports per trunk (maximum) 7 8
Trunks per switch (maximum) 4 12
