WLAN/Bluetooth combo card
The computer uses a card that provides both WLAN and Bluetooth functionality.
Table 5-4 WLAN module description and part number
Description Spare part number
Intel dual-band wireless-AC 9560 802.11ac 2 × 2 Wi-Fi + Bluetooth 5.0 combo adaptor (non-vPro) L22634-001
Before removing the WLAN module, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 29).
2. Place the computer in Battery Safe mode (Battery Safe mode on page 29).
3. Remove the bottom cover (Bottom cover on page 30).
4. Remove the battery (Battery on page 31).
Remove the WLAN module:
1. Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module.
NOTE: The WLAN antenna cable labeled 1 connects to the WLAN module Main terminal labeled 1. The
WLAN antenna cable labeled 2 connects to the WLAN module Aux terminal labeled 2. If the computer is
equipped with an 802.11a/b/g/n WLAN module, the yellow WLAN antenna cable connects to the middle
terminal on the WLAN module.
2. Remove the Phillips M2.0 × 2.5 screw (2) that secures the WLAN module to the computer. (The edge of
the module opposite the slot rises away from the computer.)
Component replacement procedures 33
