HP mt22 User Manual

Display assembly
Before disassembling the display assembly, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 29).
2. Place the computer in Battery Safe mode (Battery Safe mode on page 29).
3. Remove the bottom cover (Bottom cover on page 30).
4. Remove the battery (Battery on page 31).
Disassemble the display assembly:
1. Remove the display assembly from the computer:
a. Disconnect the antenna cables from the WLAN module (1).
b. Disconnect the display cable from the system board ZIF connector (2).
c. Remove the four Torx T8 2.5 × 4.0 screws (1) that secure the display assembly to the computer.
Component replacement procedures 51
