M.2 solid-state drive
Table 5-5 Solid-state drive descriptions and part numbers
Description Spare part number
128 GB, SATA-3, TLC L85346-002
Before removing the solid-state drive, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 29).
2. Place the computer in Battery Safe mode (Battery Safe mode on page 29).
3. Remove the bottom cover (Bottom cover on page 30).
4. Remove the battery (Battery on page 31).
Remove the solid-state drive:
1. Remove the Phillips M2.0 × 2.5 screw (1) that secures the solid-state drive to the computer.
2. Remove the solid-state drive (2) by pulling the module away from the slot at an angle.
Reverse this procedure to install the solid-state drive.
Component replacement procedures 35
