Fingerprint reader
Table 5-12 Fingerprint reader description and spare part number information
Description Spare part number
In luminous green nish L51744-001
In natural silver nish L19163-001
In plum mauve nish L51743-001
In rose gold nish L19164-001
Before removing the ngerprint reader, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the computer
on, and then shut it down through the operating system.
2. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 51).
5. Remove the battery (see Battery on page 53).
Remove the ngerprint reader:
1. Lift the plastic bracket out of the computer (1).
2. Disconnect the cable from the system board ZIF connector (2).
3. Remove the ngerprint reader module and cable from the computer (3).
Reverse this procedure to install the ngerprint reader.
78 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
