System board
NOTE: All system board spare part kits include a processor and replacement thermal material.
Table 5-14 System board description and part number
Description Spare part number
System board for use in models with discrete graphics equipped with the following processors:
Intel Core i7-8565U processor and 4 GB of MX 250 discrete video memory L50260-xx1
Intel Core i7-8565U processor and 2 GB of MX 250 discrete video memory L50259-xx1
Intel Core i7-8565U processor and 4 GB of GTX 1050 discrete video memory L34171-xx1
Intel Core i7-8565U processor and 4 GB of GeForce MX150 discrete video memory L34176-xx1
Intel Core i7-8565U processor and 2 GB of GeForce MX150 discrete video memory L34175-xx1
Intel Core i7-8565U processor with 3 GB of GTX discrete video memory L46518-xx1
Intel Core i7-8565U processor with 4 GB of GTX 1050Ti discrete video memory L34172-xx1
Intel Core i7-8550U processor and 4 GB of GeForce MX150 discrete video memory L22820-xx1
Intel Core i7-8550U processor and 2 GB of GeForce MX150 discrete video memory L22817-xx1
Intel Core i7-8550U processor and 2 GB GeForce MX130 discrete video memory L22814-xx1
Intel Core i5-8265U processor and 2 GB of GeForce MX250 discrete video memory L50258-xx1
Intel Core i5-8265U processor and 2 GB of GTX 1050 discrete video memory L34170-xx1
Intel Core i5-8265U processor and 2 GB of GeForce MX130 discrete video memory L34173-xx1
Intel Core i5-8265U processor and 2 GB of GeForce MX150 discrete video memory L34174-xx1
Intel Core i5-8265U processor with 4 GB of GTX 1050Ti discrete video memory L44879-xx1
Intel Core i5-8265U processor with GTX and 3 GB of GeForce MX150 discrete video memory L52957-xx1
Intel Core i5-8250U processor and 4 GB of GeForce MX150 discrete video memory L22818-xx1
Intel Core i5-8250U processor and 2 GB of GeForce MX150 discrete video memory L22815-xx1
Intel Core i5-8250U processor and 2 GB of GeForce MX130 discrete video memory L22813-xx1
Intel Core i7-7500U processor and 4 GB of GeForce MX150 discrete video memory L22819-xx1
Intel Core i7-7500U processor and 2 GB of GeForce MX150 discrete video memory L22816-xx1
Intel Core i3-8130U processor and 2 GB of GeForce MX150 discrete video memory L37245-xx1
System board for use in models with UMA graphics equipped with the following processors:
Intel Core i7-8565U processor L50262-xx1
Intel Core i7-8550U processor L22822-xx1
Intel Core i5-8250U processor L22821-xx1
Intel Core i3-8145U processor L50261-xx1
Intel Core i3-8130U processor L22824-xx1
Intel Core i5-8265U processor L34169-xx1
Intel Pentium 4415U processor L22823-xx1
70 Chapter 5 Removal and replacement procedures for authorized service provider parts
