4–6 Maintenance and Service Guide
Removal and replacement procedures
Computer feet
The computer feet are adhesive-backed rubber pads. The feet are included in the Rubber Kit, spare part number
580697-001. There are 4 rubber feet that attach to the base enclosure in the locations shown in the following
illustration.
Battery
Before removing the battery, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
Remove the battery:
1. Turn the computer upside down on a flat surface, with the battery bay toward you.
2. Slide the battery release latch 1 to release the battery.
3. Rotate the battery toward you and up 2.
4. Remove the battery 3.
Description Spare part number
Battery, 6-cell, 2.58-Ah (57-Wh) 580686-001
