Maintenance and Service Guide 7–1
7
Screw listing
This chapter provides specification and reference information for the screws used in the computer. The screws
listed in this chapter are available in the Screw Kit, spare part number 580698-001.
Phillips PM2.0×3.0 screw
Where used: One screw that secures the LED module to the top cover
Color Quantity Length Thread Head diameter
Silver 1 3.0 mm 2.0 mm 5.0 mm
