6–2 Maintenance and Service Guide
Specifications
13.3-in LED HD display specifications
Metric U.S.
Dimensions
Height 17.8 cm 7.0 in
Width 28.4 cm 11.2 in
Diagonal 33.6 cm 13.3 in
Number of colors Up to 16.8 million
Contrast ratio 250:1 (typical)
Brightness 200 nits (typical)
Pixel resolution
Pitch 0.279 × 0.279 mm
Format 1366 × 768 or 1280 × 720
Configuration RGB vertical stripe
Backlight LED
Character display 80 × 25
Total power consumption 4.0 W
Viewing angle ±40° horizontal, +120°/-40° vertical (typical)
