Display assembly subcomponents
Table 3-2 Display components and their descriptions
Item Component Spare part number
(1) Display bezel L72717-001
(2) Display panel (includes display cover adhesive and bezel tape):
220 nits, slim (3.2 mm) L71938-001
250 nits, slim (3.2 mm) L71939-001
300 nits, eDP 1.2, ultraslim (2.6 mm) L71940-001
300 nits, eDP 1.4, ultraslim (2.6 mm) L71941-001
(3) Display hinges (includes left and right hinges) L72710-001
(4) Webcam/microphone module (includes display cover adhesive and bezel tape) L72721-001
(5) Display panel and camera cable (includes display cover adhesive and bezel tape):
For use in models without a 144 Hz display L72719-001
For use in models with a 144 Hz display L72720-001
(6) Wireless antennas (includes display cover adhesive and bezel tape) L75188-001
(7) Display back cover (includes bezel tape)
For use in ghost white models with a 3.2 mm display panel L72711-001
For use in acid green models with a 3.2 mm display panel L72713-001
Display assembly subcomponents 17
