Hard drive assembly
Table 5-4 Hard drive and connector descriptions and part numbers
Description Spare part number
Hard drive, 1 TB, 7200 rpm 766644-005
Hard drive, 1 TB, 5400 rpm 762990-005
Hard drive connector/cable L72698-001
Before removing the hard drive assembly, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 27).
2. Remove the bottom cover (see Bottom cover on page 28).
3. Disconnect the battery (see Battery on page 37).
Remove the hard drive assembly:
1. Disconnect the hard drive cable from the system board ZIF connector (1).
2. Remove the three Phillips M2.0 × 2.5 screws (2) that secure the hard drive assembly to the computer.
3. Lift the hard drive assembly out of the computer (3).
Component replacement procedures 33
