Replacing Small Parts
(User-Replaceable)
The user can replace the following small parts.
Table 2-4. Replacing Small Parts
Part Replacement Procedure
Rubber screw plugs,
display (on display bezel)
Insert a small flat-blade screwdriver under the rubber screw plug and pry it
loose. To replace, firmly press the adhesive side of the screw plug into the
recess.
Door, mini-PCI
On the bottom of the notebook, loosen the screws that secure the mini-PCI
door to the bottom case and then remove the door.
Door, memory
On the bottom of the notebook, loosen the screws that secure the SDRAM
module door to the bottom case and then remove the door.
Feet, rubber (on bottom of
notebook)
Insert a small flat-blade screwdriver under the foot and pry it loose. To replace,
firmly press the adhesive side of the foot into the recess.
Rubber cover, docking port
(XE4500 only)
Grasp the rubber docking port cover with your fingers and gently remove it. To
replace, firmly press the docking port cover into the opening in the bottom
case.
Cover, modem port
Insert a small flat-blade screwdriver at the top of the cover and gently pry it
loose. To replace, insert the cover into the modem port opening.
Service Manual Removal and Replacement 2-11
