PIM-DM (Dense Mode) on the 5300xl Switches

Exceptions to Support for RFC 2932 - Multicast Routing MIB

Exceptions to Support for RFC 2932 -

Multicast Routing MIB

These MIB objects are not supported in the 5300XL routing switch.

ipMRouteInterfaceRateLimit

ipMRouteInterfaceInMcastOctets

ipMRouteInterfaceOutMcastOctets

ipMRouteInterfaceHCInMcastOctets

ipMRouteInterfaceHCOutMcastOctets

ipMRouteBoundaryTable

ipMRouteBoundaryEntry

ipMRouteBoundaryIfIndex

ipMRouteBoundaryAddress

ipMRouteBoundaryAddressMask

ipMRouteBoundaryStatus OBJECT-TYPE

ipMRouteScopeNameTable

ipMRouteScopeNameEntry

ipMRouteScopeNameAddress

ipMRouteScopeNameAddressMask

ipMRouteScopeNameLanguage

ipMRouteScopeNameString

ipMRouteScopeNameDefault

ipMRouteScopeNameStatus

5-41
