Rear panel components
1 Power Cord Connector 7 Voltage Select Switch (included on some
models only)
2
Line-In Audio Connector (blue) 8 Line-Out Connector for powered audio
devices (green)
3
DisplayPort Monitor Connector 9 USB 2.0 Ports (black)
4
Serial Connector 10 VGA Monitor Connector
5
RJ-45 Network Connector 11 PS/2 Keyboard Connector (purple)
6
PS/2 Mouse Connector (green)
NOTE: An optional second serial port and an optional parallel port are available from HP.
The integrated graphics cannot be enabled when a discrete graphics card is installed.
Rear panel components 3
