Removing a 2.5-inch hard drive
NOTE: Before you remove the old hard drive, be sure to back up the data from the old hard drive so that
you can transfer the data to the new hard drive.
1. Prepare the computer for disassembly (Preparation for disassembly on page 23)
2. Remove the access panel (
Access panel on page 24)
3. Disconnect the power cable and data cable from the back of the hard drive.
4. Disconnect the power cable and data cable from the back of the hard drive.
5. Remove the four 6-32 mounting screws (1) and slide the drive out of the bay (2).
40 Chapter 5 Removal and replacement procedures: Microtower
