System Features
HP ProLiant ML110 Server Operations and Maintenance Guide 1-3
•
•
•
•
•
•
•
•
•
•
•
•
•
•
System Specifications
Physical Specifications
Height – 430 mm (16.93 in.)
Width – 200 mm (7.87 in.)
Depth – 500 mm (19.69 in.)
Weight
— Basic configuration approximately 16.5 kg. (36.24 lbs) – excludes keyboard and
monitor.
— Fully loaded approximately 22 kg. (47.41lbs) – excludes keyboard and monitor.
Environmental Specifications
Temperature
— Operating: +10 to +35°C (+50 to +95°F)
— Non-operating: -10 to +60°C (+14 to +140°F)
Humidity
— Operating: 20% to 80% RH, non-condensing
— Non-operating: 20% to 90% RH, non-condensing
— Storage: 20% to 90% RH, non-condensing
Altitude
— Operating: -16 to 3,048 m (-50 to 10,000 ft)
— Non-operating: -16 to 10,600 m (-50 to 35,000 ft)
Thermal output
— Maximum operating: 1907 BTU/hr
Acoustic emissions
— Normal configuration: LpA: <35dBA, operating at room temperature
— Maximum configuration: LpA: <70dBA
Power Supply Requirements
Input type: AC
Input maximum range: 100 to 127 VAC@45/66Hz / 200 to 240 VAC@45/66Hz
Maximum current: 115VAC @8.0A
Inrush current: 80A@115AVC
Operating power: 350W @25°C; 320W @50°C
