Mounting the RP2 to a wall, swing arm, or pole-mounted bracket
The RP2 can be attached to a wall, swing arm, pole-mounted bracket, or other mounting fixture. This RP2
supports the VESA industry standard 100 mm spacing between mounting holes.
NOTE: There are two sets of VESA industry standard screw holes on the rear: a 75 mm x 75 mm pattern (1)
and a 100 mm x 100 mm pattern (2). The stand attaches to the 75 mm x 75 mm pattern. The 100 mm x 100
mm pattern can be used to attach a mounting device, such as the HP Quick Release.
This apparatus is intended to be supported by UL or CSA Listed wall mount bracket. HP recommends that you
use an HP Quick Release mounting bracket for wall mounting (part number EM870AA).
CAUTION: To attach a third-party mounting solution to the RP2, four 4 mm, 0.7 pitch, and 10 mm long
screws are required. Longer screws must not be used because they may damage the system. It is important
to verify that the manufacturer’s mounting solution is compliant with the VESA standard and is rated to
support the weight of the system.
20 Chapter 5 Removal and replacement procedures
