4. Press the module connectors firmly into the flash memory module socket (1), making sure that
the retention post on the system board is aligned with the hole in the module.
Figure 2-14 Securing the flash memory module
5. Insert the screw provided in the flash memory module option kit through the hole in the module
into the retention post (2) and tighten to secure the module.
Replacing an internal hard drive
Before beginning the replacement process, review General hardware installation sequence on page 9
for procedures you should follow before and after installing or replacing hardware.
WARNING! You must remove the left side panel to access the system board. Before removing the
side access panel, ensure that the thin client is turned off and the power cord is disconnected from
the electrical outlet.
Removing an internal hard drive
To remove an internal hard drive:
1. If a PCI-Express card is installed, remove it.
Installing thin client options 21
