3. Align the PCIe card connector with the PCI riser card socket and the expansion slot. Press the
PCIe card firmly into the socket to ensure that the PCIe card is seated correctly and that the
connector fits the expansion slot properly (1).
Figure 2-22 Installing the PCIe card
4. Close the metal latch to secure the PCIe card (2).
Installing external drives
Various external USB drives are available as options for the t610 Series Thin Clients. For more
information about these drives, visit
http://h10010.www1.hp.com/wwpc/us/en/sm/WF12a/
12454-12454-321959.html, or refer to the instructions that accompany the option.
For more information about available options, visit the HP website at
http://h10010.www1.hp.com/
wwpc/us/en/sm/WF12a/12454-12454-321959.html.
26 Chapter 2 Hardware changes
