Table 14-1 Security > GRE VPN > Setup
Label Description
Add New
T
unnel
Click this button to create a new GRE tunnel.
# This shows the index number of the rule. Select the checkbox next to the
rule to activate it.
Enabled
This shows whether the GRE tunnel is turned on or off.
GRE Tunnel
Name
This shows the name of this tunnel.
GRE Layer This shows either OSI layer 2 or layer 3 protocol the GRE tunnels over
a network.
GRE Server IP This is the IP address or domain name of the remote gateway to which
the LTE Device's WAN interface tunnels traffic.
GRE Local IP This is the local hosts' IP addresses for which the LTE Device tunnels
traffic sent to the remote gateway.
GRE Remote IP This is the remote hosts' IP addresses behind the remote gateway to
which the LTE Device tunnels traffic.
Modify Click the Edit icon to go to the screen where you can edit the tunnel.
Click the Delete icon to delete an existing tunnel.
14.2.1 The Add/Edit GRE Tunnel Screen
Use this screen to create or modify a GRE VPN tunnel. Click the Add New Tunnel button or
an
Edit icon next to a VPN tunnel in the Security > GRE VPN screen to open the following
screen.
LTE CPE B2368
User Guide
14 GRE VPN
Issue 03 (2019-01-31) Copyright © Huawei Technologies Co., Ltd. 103
