license and then import it. For details, see 6.3.2 Applying for a License (Only for
the CX210 and CX912) and 6.3.8 Importing and Transferring Licenses (Only
for the CX210 and CX912).
– If the preceding licenses do not exist, you do not need to perform any operation on
the license.
l You may need to upgrade software during the replacement. Therefore, obtain the latest
software of the switch module to be replaced at the Huawei technical support website
before the replacement.
l If the switch module to be replaced is CX710:
a. Run the following command on the CLI of the 40GE converged switching plane to
check the current version of the 40GE converged switching plane:
<HUAWEI> display version
Figure 6-12 Displayed information (example)
b. Confirm the PCB version of the CX710.
n If PCB Version is VER A, continue to replace the switch module.
n If PCB Version is VER B, the CPLD software cannot be rolled back to
version 0.08 or 0.09.
Table 6-1 Preparations
Item
Name Description
Software TFTP server software An example is tftpd32.exe,
which is used to remotely
connect to a switch module.
E9000 Server
User Guide
6 Parts Replacement
Issue 25 (2019-11-30) Copyright © Huawei Technologies Co., Ltd. 111

Huawei E9000 Specifications

General

Form Factor	12U chassis
Blade Slots	16 half-width slots or 8 full-width slots
Switch Modules	GE, 10GE, and IB switches
Management Modules	Two hot-swappable management modules for redundancy
Power Supply	Supports up to 6 hot-swappable power supply units (PSUs)
Cooling	Redundant hot-swappable fan modules
Processor Options	Intel Xeon E5-2600 v3/v4 series processors (depending on blade type)
Memory Capacity	Up to 1.5 TB per blade
Storage Options	SAS/SATA/SSD options in blades
Networking	10GE/40GE networking options
Management	Huawei iBMC (Intelligent Baseboard Management Controller)
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Windows Server, VMware ESXi
