Huawei E9000 User Manual

l Floating nut hook
Auxiliary Materials
l Screws (M6)
l Cable ties
l Fiber binding tapes
l Corrugated pipes
l Floating nuts
Components
l Compute nodes
l Switch modules
l PGND cables
l Ethernet signal cables
l Power cables
l Optical modules
l Optical cables
3.2 Unpacking the Chassis Packing Case
Procedure
Step 1 Check the packaging and the seal on the packing case.
If the packing case is damaged (for example, the packing case is wet or deformed, or the seal or
pressure-sensitive tape is unsealed), preserve onsite evidence and report the actual conditions to the
supplier or Huawei Technologies Co., Ltd.
Step 2 Use a pallet truck to carry the chassis to the equipment room, and remove the pallet truck.
Figure 3-2 Carrying a chassis
E9000 Server
User Guide
3 Installing the E9000
Issue 25 (2019-11-30) Copyright © Huawei Technologies Co., Ltd. 46

Huawei E9000 Specifications

General

Form Factor	12U chassis
Blade Slots	16 half-width slots or 8 full-width slots
Switch Modules	GE, 10GE, and IB switches
Management Modules	Two hot-swappable management modules for redundancy
Power Supply	Supports up to 6 hot-swappable power supply units (PSUs)
Cooling	Redundant hot-swappable fan modules
Processor Options	Intel Xeon E5-2600 v3/v4 series processors (depending on blade type)
Memory Capacity	Up to 1.5 TB per blade
Storage Options	SAS/SATA/SSD options in blades
Networking	10GE/40GE networking options
Management	Huawei iBMC (Intelligent Baseboard Management Controller)
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Windows Server, VMware ESXi
