Huawei S5700 Series Hardware Description

1 Twenty-four 10/100/1000BASE-T ports 2 Two 1000BASE-X ports
Applicable modules and cables:
l GE optical module
l GE-CWDM optical module
l GE-DWDM optical module
l GE copper module
l Stack optical module (applicable in
V200R007C00 and later versions)
l 1 m and 10 m SFP+ copper cables
l 3 m and 10 m AOC cables
3 Two combo ports (10/100/1000BASE-T
+ 100/1000BASE-X)
Modules applicable to combo optical
ports:
l FE optical module
l GE optical module
l GE-CWDM optical module
l GE-DWDM optical module
4 One mini USB port
5 One console port 6 Ground screw
NOTE
It is used with a ground cable.
7 RPS socket
NOTE
It is used with an RPS cable, which is not
hot swappable.
8 Jack for AC terminal locking latch
NOTE
The AC terminal locking latch is not
delivered with the switch.
9 AC socket
NOTE
It is used with an AC power cable.
- -
Port Description
10/100/1000BASE-T port
A 10/100/1000BASE-T Ethernet electrical port sends and receives service data at
10/100/1000 Mbit/s, and must use network cables. Table 3-47 describes the attributes of a
10/100/1000BASE-T Ethernet electrical port.
Table 3-47 Attributes of a 10/100/1000BASE-T Ethernet electrical port
Attribute
Description
Connector type RJ45
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
116
