Hunter AC solenoids and valves.
Valve Wire Sizing (Maximum One-Way Distance in Feet Between Controller and Valve)
Ground
Wire Size
Control Wire (ft)
18 AWG /
1.0 mm
16 AWG /
1.2 mm
14 AWG /
1.6 mm
12 AWG /
2.0 mm
10 AWG /
2.5 mm
8 AWG / 3
mm
6 AWG / 4
mm
18 AWG / 1.0
mm
850 1040 1210 1350 1460 1540 1590
16 AWG / 1.2
mm
1040 1340 1650 1920 2150 2330 2440
14 AWG / 1.6
mm
1210 1650 2150 2630 3080 3450 3700
12 AWG / 2.0
mm
1350 1920 2630 3390 4170 4880 5400
10 AWG / 2.5
mm
1460 2150 3080 4170 5400 6670 7690
8 AWG / 3
mm
1540 2330 3450 4880 6670 8700 10530
6 AWG / 4
mm
1590 2440 3700 5400 7690 10530 13330
Pump Start Relay Wiring and
Online Setup
In this article, we will discuss the following topics:
Summary
Operation Chart
Wiring (24 VAC)
Wiring to Power Source
Online Setup
Pump Start Relay Operation per Zone
Summary
