Pump Start Relay Operation per Station
When selecting a PUMP START RELAY to be on/off for an individual zone, you can edit
the zone in ZONES AND SCHEDULES under ADVANCED SETTINGS. This option is
useful when one zone is using city water and another is using water from a different
source.
NOTE: This option is for HPC and HCC controllers only.
Follow the steps below to change this setting:
1. From the ZONES AND SCHEDULES page, click on the icon on the zone you would
like to edit.
2. Click on ADVANCED, which is located on the top blue search section.
3. Select USE GLOBAL MASTER VALVE SETTING to keep this circuit on or select
DISABLE MASTER VALVE to turn it off.
