18
4.4 Connecting Accessories
WARNING: Do not lift the monitor by the sensor cables, or power cord
because the cable could disconnect from the monitor, causing the
monitor to drop on the patient.
Note: For the safety of patients, and to ensure the best product
performance and accuracy, use accessories provided with the
Smartsigns
®
Compact 300 only, or accessories recommended by
Huntleigh Healthcare Ltd Service Department.
NIBP Hoses and Cuffs
NIBP Hose Connector
1. Select the appropriate size cuff for the patient and apply the cuff to the selected
site.
2. Connect the hose to the NiBP connector on the side of the unit.
SpO2 Cables and Sensors
SpO2 Interface cable connector
1. Select an appropriate sensor for the patient and desired application.
2. Apply the sensor to the selected site.
3. Connect the SpO2 sensor to the side of the unit.
Setting up the Monitor
