Husqvarna AUTOMOWER 435X AWD User Manual

3.10.5.1 To start to use Automower
®
Direct
1. Download the Automower
®
Connect app on
your mobile device.
2. Select Automower
®
Direct on the start
screen of the Automower
®
Connect app.
3. Start Bluetooth
®
on your mobile device and
on the product, refer to
To start the product
for the first time on page 30
.
4. Go to the Settings symbol in the display and
activate Bluetooth
®
.
5. Select the product to pair with in the
Automower
®
Connect app.
6. Enter the PIN code for the product.
Note: You have access to the menus and
functions as long as you are in Bluetooth
®
short-
range.
3.10.6 User interface overview
The user interface overview below shows examples of Automower
®
Connect and the corresponding
display in Automower
®
Access.
Automower
®
Connect
ERROR
Charging station Blocked
MORE DETAILS
Schedule Map
My Automower
R
MOWING
Mowing session ends 13:30
PARK PAUSE
Schedule Map
My Automower
6
R
PARKED
Next start tomorrow 16:30
PARK START
Schedule Map
6
My Automower
R
PAUSED
Ends 13:30
PARK START
Schedule Map
My Automower
R
6
6
Automower
®
Access
6 6
P
6
6
3.11 To start the product for the first
time
When the product is switched on for the first time,
there are some basic settings to do before the
product can start to operate.
1. Push the jog wheel for 3 seconds to switch
on the product.
30 - Installation 1404 - 002 -

Husqvarna AUTOMOWER 435X AWD Specifications

General

Cutting Width	22 cm
Cutting Height, Min-Max	30-70 mm
Battery Type	Li-Ion
Typical Charging Time	30 min
Typical Mow Time on One Charge	100 min
Product Size, LxWxH	93x55x29 cm
Maximum Slope Performance Inside Installation	70%
Working Area Capacity	3500 m²
Battery Voltage	18 V
Battery Capacity	5.0 Ah
Guide Wire	Yes
GPS-assisted Navigation	Yes
Lift Sensor	Yes
Tilt Sensor	Yes
Ultrasonic Sensor	Yes
Connectivity	Bluetooth, Cellular
Weather Resistance	Yes
Warranty	2 years
Blade Type	Pivoting Razor Blades
