Husqvarna AUTOMOWER 435X AWD User Manual

5.4.4 To install the rear top cover
1. Put the top cover on the rear body.
2. Put the top cover in position (A) and push
the 2 magnets to assemble the top cover
(B).
A
B
5.5 Battery
WARNING: Only charge the product
using a charging station and power
supply which is intended for it.
Incorrect use may result in electric
shock, overheating or leakage of
corrosive liquid from the battery. In the
event of leakage of electrolyte flush
with water and seek medical help if it
comes in contact with the eyes etc.
WARNING: Use only original batteries
recommended by the manufacturer.
Product safety cannot be guaranteed
with other batteries. Do not use non-
rechargeable batteries.
CAUTION: The battery must be
charged fully before winter storage. If
the battery is not fully charged it can
be damaged and in certain cases be
rendered useless.
The charging time can vary depending on,
among other factors, the ambient temperature.
Below indicates that the battery is getting old and
eventually needs replacing:
• The operating time for the product is shorter
than normal between charges. This leads to
44
- Maintenance
1404 - 002 -

Husqvarna AUTOMOWER 435X AWD Specifications

General

Cutting Width	22 cm
Cutting Height, Min-Max	30-70 mm
Battery Type	Li-Ion
Typical Charging Time	30 min
Typical Mow Time on One Charge	100 min
Product Size, LxWxH	93x55x29 cm
Maximum Slope Performance Inside Installation	70%
Working Area Capacity	3500 m²
Battery Voltage	18 V
Battery Capacity	5.0 Ah
Guide Wire	Yes
GPS-assisted Navigation	Yes
Lift Sensor	Yes
Tilt Sensor	Yes
Ultrasonic Sensor	Yes
Connectivity	Bluetooth, Cellular
Weather Resistance	Yes
Warranty	2 years
Blade Type	Pivoting Razor Blades
