Husqvarna AUTOMOWER 435X AWD User Manual

6.5 Indicator lamp in the charging
station
For a fully functional installation, the indicator lamp in the charging station must emit a solid or flashing
green light. If something else appears, follow the troubleshooting guide below.
There is more help on www.husqvarna.com. If you still need help, please contact your local Husqvarna
representative.
Light Cause Action
Green solid light Good signals. No action required.
Green flashing
light
The signals are good and ECO mode is
activated.
No action required.
Blue flashing light The boundary loop is not connected to
the charging station.
Check that the boundary wire connec-
tors are fitted properly to the charging
station.
Break in the boundary loop. Find out where the break is. Replace
the damaged section of the loop with a
new loop wire, and splice using an orig-
inal coupler.
Red flashing light Interruption in the charging station’s an-
tenna.
Contact your local Husqvarna repre-
sentative.
Red solid light Fault in the circuit board or incorrect
power supply in the charging station.
The fault should be rectified by an au-
thorized service technician.
Contact your local Husqvarna repre-
sentative.
1404 - 002 - Troubleshooting - 55

Husqvarna AUTOMOWER 435X AWD Specifications

General

Cutting Width	22 cm
Cutting Height, Min-Max	30-70 mm
Battery Type	Li-Ion
Typical Charging Time	30 min
Typical Mow Time on One Charge	100 min
Product Size, LxWxH	93x55x29 cm
Maximum Slope Performance Inside Installation	70%
Working Area Capacity	3500 m²
Battery Voltage	18 V
Battery Capacity	5.0 Ah
Guide Wire	Yes
GPS-assisted Navigation	Yes
Lift Sensor	Yes
Tilt Sensor	Yes
Ultrasonic Sensor	Yes
Connectivity	Bluetooth, Cellular
Weather Resistance	Yes
Warranty	2 years
Blade Type	Pivoting Razor Blades
