Husqvarna AUTOMOWER 435X AWD User Manual

5. Remove the 3 screws. Use a manual
straight slot or cross-tip screwdriver.
6. Remove each blade and screw.
7. Fasten new blades and screws.
8. Check that the blades can pivot freely.
5.4 To replace the top covers
The top cover is an accessory available in
different colors. Speak to your local Husqvarna
representative for more information.
CAUTION:
Clean grass and dirt from
the product before you remove the
covers.
5.4.1 To remove the front top cover
1. Push the STOP button to stop the product.
2. Remove the front top cover from the snap-
on clips on the product.
3. Lift the front top cover.
5.4.2 To install the front top cover
1. Put the front top cover on the snap-on clips.
42
- Maintenance
1404 - 002 -

Husqvarna AUTOMOWER 435X AWD Specifications

General

Cutting Width	22 cm
Cutting Height, Min-Max	30-70 mm
Battery Type	Li-Ion
Typical Charging Time	30 min
Typical Mow Time on One Charge	100 min
Product Size, LxWxH	93x55x29 cm
Maximum Slope Performance Inside Installation	70%
Working Area Capacity	3500 m²
Battery Voltage	18 V
Battery Capacity	5.0 Ah
Guide Wire	Yes
GPS-assisted Navigation	Yes
Lift Sensor	Yes
Tilt Sensor	Yes
Ultrasonic Sensor	Yes
Connectivity	Bluetooth, Cellular
Weather Resistance	Yes
Warranty	2 years
Blade Type	Pivoting Razor Blades
