English – 11
2.8 . To disassemble/assemble the
motor/pump unit, PW 350, PW 360
1. Disassemble parts until there is free access to the
motor/pump unit.
2. Remove the internal hose from the pump by removing
the U-pin. Make sure that you do not loose the spring
and the Non Return Valve (NRV) from the water outlet!
2.9 To disassemble/assemble the
hose reel/internal hose PW 350,
PW 360
1. Remove 1 torx TX20 screw to remove the motor/pump
unit back cover.
2. Now you have access to the internal hose.
Repair instructions
