English – 17
3 Specications
3.1 Technical data
Value Unit PW 345C PW 350 PW 360
1
PW 360
2
Max pressure bar 145 150 160 160
Voltage V 230 230 230 230-240
Frequency Hz 50 50 50 50
Rated current A 10 9.5 10 9.6
Power consumption kW 2.4 2.1 2.3 2.3
Motor speed min
-1
17.500-18.000 2800 2800 2800
Flow rate, HP l/min 7 7 6.8 7
Pump pressure bar 122 ±9 122 ±9 160 160
Nozzle pressure bar 115 ±9 115 ±9 115 ±9 115 ±9
Standby pressure bar 15-35 15-35 15-35 15-35
Retaining time min 5 5 5 5
Oil contents ml 60 80 80 80
Oil type - LHM32 LHM32 LHM32 LHM32
Max water inlet temperature °C 40 40 40 40
Max water inlet pressure bar 10 10 10 10
High pressure hose length m 8-10m 9-10 9-10 9-10
Suction height m 1 1 1 1
Electric cable m 5 5 5 5
Insulation class - F F F F
Tightness - IPX5 IPX5 IPX5 IPX5
1 = 230V / 50Hz
