English – 9
2.4 To disassemble/assemble the
start/stop system
1. Remove the micro switch box by hand. Now you have
free access to the start/stop valve.
2. Remove the start/stop valve with a 25 mm spanner.
3. Assembly: Check that all parts are correctly
assembled, see gure below. Install the start/stop valve.
2.5 To disassemble/assemble the
switch box cover
1. Tools: Torx 20 screwdriver.
2. Remove 1 torx TX20 screw (A).
3. Note how the wires are installed. Remember to install
the foam (B) during assembly.
A
B
Repair instructions
