POWER SUPPLY SETUP
2-6 powermax 65/85 Operator Manual
Power connection for the Powermax65
The Powermax65 CSA model is a universal power supply that can configure itself to operate with
AC voltages from 200 to 600, 1- or 3-phase. The CE model is 380/400 V, 3-phase only. The rated
output is 25 – 65A, 139 VDC.
CSA model Single-phase Three-phase
Input voltage 200-208 230-240 480 200-208 230-240 400 480 600
Input current at 9.0
kw output
52 44 22 32 27 15 13 13
Input current
during arc stretch
74 74 38 45 45 27 23 23
Fuse (slow-blow) 80 80 40 50 50 30 25 25
CE model Three-phase
Input voltage 380/400
Input current at 9.0
kw output
15.5/15
Input current
during arc stretch
27
Fuse (slow-blow) 30
