IBC Qscan User Manual

Qscan User’s Guide Version 1.4
Page 26
Wiegand Output Format # 1 (for barcode data)
X015 a mmmm ssss sd bbbb
X016 bd iiii id ss bb ii
X017 x y z lpp rpp h i j k
a active indicator 0=inactive 1=active
mmmm barcode length 0-1500 0000=any
ssss site code start 0000=no site
sd site code digits 00=remaining
bbbb id start 0000=no id
bd id digits 00=remaining
iiii issue code start 0000=no issue
id issue code digits 00=remaining
ss site code bits 00=none
bb id code bits 00=none
ii issue code bits 00=none
x,y,z backwards indicators 0=off (msb) 1=on (lsb)
lpp left parity bits 000=none
rpp right parity bits 000=none
h,i,j eld numbers for xmit 1=site,2=id 3=issue,0=none
k site override 0=no 1=yes
see comments on the following pages.
Wiegand Output Format # 2 (for barcode data)
X019 a mmmm ssss sd bbbb
X020 bd iiii id ss bb ii
X021 x y z lpp rpp h i j k
see Wiegand Output Format # 1 for parameter descriptions
PROGRAMMING
BARCODE -> WIEGAND OUT
