Qscan User’s Guide Version 1.4
Page 34
PROGRAMMING
EMULATIONS
Selection of Output Style
X023 a
a Type of Output 1=wiegand, wieaba, alphawie
2=magstripe, aba, f2f
3=wand emulation
This command is used to program the type of “emulation” output sent by
the reader. Qscans with a “wiegand” ordering code can be reprogrammed
to output any of the above formats.
Mag Emulation Control (rmware prior to 3/29/13)
X024 c d t f b pp ss
c cstart 0=off 1=on
d neuron mode 0=off 1=on
t track emulation 1=track 1 2=track 2 (aba)
f f2f 0=no 1=yes
b time between pulses 1 - 5 ms default=1 (1ms)
pp pulse time * 50us 1 - 5 *50us default=02 (100us)
ss data settle time *10us 1 - 2 *10us default=02 (20us)
“c” applies to track 2 (aba) output only. When on, a C start sentinel is sent
instead of a B start sentinel. Set “d” to 1 if your system requires data to
go up at the same time as the clock signal.
To transmit in f2f format, “f” must be set to 1.
!
Qscan F2F circuitry supports connection to a system with a 5V or
12V pullup.
!
