Qscan User’s Guide Version 1.4
Page 52
Special Processing Mode
X030 xx
xx special mode 00=off 01=HID 5352 37 bit emu-
lation (rs232)
The digital inputs can be used to control either of the leds, or used for an
arming loop.
Normal polarity is active low.
PROGRAMMING
MISCELLANEOUS
Bicolor Led Mode
X031 x
x led style 0=red / green
1=off / red
2=off / green
Controls the color modes of the bicolor led.
Control Card Programming Lockout
X039 x
x lockout 0=unlocked
1=locked
If set to 1 (locked), IBC control cards cannot be used to reprogram the
reader.
