Safety compliance: UL 60950-1, 2nd Edition, 2014-10-14; CAN/CSA C22.2 No. 60950-1-07, 2nd Edition,
2014-10, IEC 60950-1:2005 (Second Edition); Am1:2009 + Am2:2013; EN 60950-1:2006 + A1:2010 + A11:2009
+ A12:2011 + A2:2013
Rack switch specifications
Rack switch specifications provide detailed information for your IBM BNT RackSwitch, including
dimensions, electrical, power, temperature, environment, and service clearances.
Select the appropriate models to view the specifications for your rack switch.
G8052R RackSwitch specification sheet
Hardware specifications provide detailed information for your IBM BNT RackSwitch, including
dimensions, electrical, power, temperature, environment, and service clearances.
Table 112. Dimensions
Height Width Depth Weight (maximum)
44 mm (1.73 in.) 439 mm (17.3 in.) 445 mm (17.5 in.) 8.3 kg (18.3 lb)
Table 113. Electrical
Electrical characteristics Properties
Power requirements 200 W
Voltage 90 - 264 V ac
Frequency 47 - 63 Hz
Maximum thermal output 682.4 Btu/hr
Phase 1
kVA 0.204
Table 114. Environmental and acoustical requirements
Environment/Acoustical Operating Storage
Airflow direction Rear-to-front
Temperature, ambient operating 0°C - 40°C (32°F - 104°F)
Temperature, (fan failure) operating 0°C - 35°C (32°F - 95°F)
Temperature, storage -40ºC to +85ºC (-40°F to 185°F)
Relative humidity range
(non-condensing)
10% - 90% RH 10% - 90% RH
Maximum altitude 3050 m (10000 ft) 12190 m (40000 ft)
Heat dissipation 444 Btu/hr
Acoustic noise Less than 65 dB
G8124ER RackSwitch specification sheet
Hardware specifications provide detailed information for your IBM BNT RackSwitch, including
dimensions, electrical, power, temperature, environment, and service clearances.
Table 115. Dimensions
Height Width Depth Weight (maximum)
44 mm (1.73 in.) 439 mm (17.3 in.) 381 mm (15.0 in.) 6.4 kg (14.1 lb)
84 Site and hardware planning
