Model 7965-S42 supported feature codes:
Learn about the supported feature codes that are available for 7965-S42 racks.
Feature code (FC) ECRK
FC ECRK is an optional rear rack extender that can be used for 7965-S42 racks. This extender is installed
on the rear of the 7965-S42 rack and provides 130 mm (5 in.) of extra space to hold cables on the side of
the rack and to keep the center area clear for cooling and service access. Two extenders can be stacked to
provide 260mm (10 in.) of additional rear cabling space. The extender has hook-and-loop fasteners to
secure cables.
Table 87. Dimensions for FC ECRK rear rack extender
Width Depth Height Weight
600 mm (23.62 in.) 130 mm (5.11 in.) 1952.4 mm (76.87 in.) 14.5 kg (32 lbs)
600mm
(23.6in)
130mm
(5.12in)
192.5mm
(7.58in)
111.6mm
(4.39in)
86.3mm
(3.4in)
Cable
Egress
Cable
Egress
S42Rack
RearDoor
P8HAD506-0
Figure 41. FC ECRK rear rack extender (top cable exit)
600mm
(23.6in)
130mm
(5.12in)
108mm
(4.25in)
185mm
(7.3in)
Cable
Egress
Cable
Egress
S42Rack
RearDoor
P8HAD507-0
Figure 42. FC ECRK rear rack extender (bottom cable exit)
68 Site and hardware planning
