Table 31. Electrical
Electrical characteristics Properties
kVA (maximum) 1.684
Rated voltage and frequency 200 - 240 V ac at 50 - 60 plus or minus 0.5 Hz
Thermal output (maximum) 5461 Btu/hr
Power requirements (maximum) 1600 W
Power factor 0.95
Inrush current 80 A
Leakage current (maximum) 3.5 mA
Phase 1
Table 32. Service clearance
Front Back Sides Top
762 mm (30 in.) 762 mm (30 in.) 762 mm (30 in.) 762 mm (30 in.)
Side and top clearances are optional when operating.
Table 33. Feature code
Feature Code Top rack specify Bottom rack specify PDU support Power cords
0550
1
None None 0 to 4
2
Model 9406-830
3
, PDU
1
Ten EIA units of space not managed by the configurator.
2
Feature codes 5160, 5161, and 5162.
3
Model 9406-830 does not plug into a power distribution unit.
Model 0551 rack
The 0551 rack specifications provide detailed information for your rack.
The 0551 provides an empty 1.8 m rack (36 EIA units of total space).
Site and hardware planning 19
