Table 93. Dimensions
Width Depth Height Weight
216 mm (8.5 in.) 540 mm (21.25 in.) 438 mm (17.25 in) 19.6 - 21.4 kg (43 - 47 lb)
Table 94. Electrical
Electrical characteristics Properties
Maximum measured power 523 W
Maximum kVA .55
Frequency 50 or 60 Hz
Maximum thermal output 1784 BTU/hr
Input voltage low range 100 - 127 V ac
Input voltage high range 200 - 240 V ac
Table 95. Environment requirements
Environment System requirements Altitude
Recommended operating temperature 10°C - 35°C (50°F - 95°F) 0 - 914.4 m (0 - 3000 ft)
10°C - 32°C (50°F - 89.6°F) 914.4 - 2133.6 m (3000 - 7000 ft)
Nonoperating temperature 10°C - 43°C (50°F - 109.4°F) 2133.6 m (7000 ft)
Maximum altitude NA 2133.6 m (7000 ft)
Shipping temperature -40°C to 60°C (-40°F to 140°F)
Operating humidity 8% - 80%
Nonoperating humidity 8% - 80%
7042-CR7 Hardware Management Console specifications
Hardware specifications provide detailed information about your Hardware Management Console
(HMC), including dimensions, electrical, environmental requirements, and noise emissions.
The HMC controls managed systems, including the management of logical partitions and the use of
capacity on demand (CoD). By using service applications, the HMC communicates with managed
systems to detect, consolidate, and send information to IBM for analysis. The HMC provides service
technicians with diagnostic information for systems that can operate in a multiple-partitioned
environment.
Use the following specifications to plan for your HMC.
Table 96. Dimensions
Width Depth Height Weight (maximum
configuration)
429 mm (16.9 in.) 734 mm (28.9 in.) 43 mm (1.7 in.) 16.4 kg (36.16 lb)
Table 97. Electrical requirements
Electrical characteristics Properties
Maximum measured power 351 W
Maximum thermal output 1198 Btu/hr
Input voltage low range 100 - 127 V ac
Input voltage high range 200 - 240 V ac
78 Site and hardware planning
