Table 46. Feature code 0588 - PCI-X expansion unit in rack (continued)
IBM rack Rack, specify code PDU support Power cords
1
0551 is an empty 1.8 meter rack with 36 EIA units of total space. 0553 is a 2.0 meter rack with 42 EIA units of total
space.
2
0551, 0553, and 0555 feature codes 5160, 5161, 5163, and 7188. 7014 feature codes 7176, 7177, 7178, and 7188.
3
0588 comes with two rack power cords that plug into a PDU.
Feature code 0595 - PCI-X expansion unit in rack
Table 47. Feature code 0595 - PCI-X expansion unit in rack
IBM rack Rack, specify code PDU support Power cords
0551
1
0553
1
0555
0595 0 to 4
2
0595, PDU
3
1
0551 is an empty 1.8 meter rack with 36 EIA units of total space. 0553 is a 2.0 meter rack with 42 EIA units of total
space.
2
0551, 0553, and 0555 feature codes 5160, 5161, 5163, and 7188. 7014 feature codes 7176, 7177, 7178, and 7188.
3
If unit plugs into a PDU, feature code 1422 is required. If redundant power supply (feature code 5138) is ordered,
a second feature code 1422 is required.
Note: Supported only on MES orders and includes a rack shelf with rail assembly, adapter plate, and
cable-management-arm assembly.
Model 0551 and 9406-270 rack
Server specifications provide detailed information for your server, including dimensions, electrical, power,
temperature, environment, and service clearances.
Pictured is model 0551 and 9406-270 rack. The 0551 consists of two models 9406-270 with 7104 system
unit expansions installed in a 1.8 m rack. Specify code 0121 represents the first model 9406-270 in the rack
(on the bottom). Specify code 0122 represents the second model 9406-270 in the rack (on the top).
28 Site and hardware planning
