Table 137. Intelligent Switched PDU specifications
Characteristics Properties
Height 43.9 mm (1.73 in.)
Width 447 mm (17.6 in.)
Depth 350 mm (13.78 in.)
Additional clearance 25 mm (0.98 in.) for circuit breakers
3 mm (0.12 in.) for outlets
Weight (not including power cord) 6.3 kg (13.8 lb)
Weight of power cord (approximate) 5.4 kg (11.8 lb)
Operating temperature at 0 - 914 m (0 - 3000 ft)
(room ambient)
10°C - 60°C (50°F - 140°F)
Operating temperature at 914 - 2133 m (3000 -
7000 ft) (room ambient)
10°C - 60°C (50°F - 140°F)
Operating humidity 8 - 80% (noncondensing)
Localized air temperature in PDU 60 °C (140 °F) maximum
Rated frequency (all feature codes) 50 - 60 Hz
Circuit breakers Nine double-pole branch rated circuit breakers rated at 20 amps
for 1U C19 PDU models.
Six double-pole branch rated circuit breakers rated at 20 amps for
1U C13 PDU models.
The intelligent, switched AC power distribution unit (PDU) provides the capability to monitor the
amount of electrical power that is being used by devices that are plugged into the PDU. The PDU can
also cycle power to individual receptacles by using the switched function.
Table 138. EPTK/EPTL circuit breaker wiring
Circuit breaker number IEC 320-C19 receptacle IEC 320-C13 receptacle
1 1 1
2 2
3 3
4 4 4
5 5
6 6
7 7 7
8 8
9 9
Calculating the power load for 7188 or 9188 power distribution units
Learn how to calculate the power load for power distribution units.
Rack-mounted 7188 or 9188 power distribution unit
Learn about the power loading requirements and proper loading sequence for the 7188 or 9188 power
distribution unit.
Site and hardware planning 117
