Planning for the 7014-T00 and 7014-T42 racks
Rack specifications provide detailed information for your rack, including dimensions, electrical, power,
temperature, environment, and service clearances.
Some products can have rack installation limitations. Refer to the specific server or product specifications
for any restrictions.
The following provide specifications for the 7014-T00, and 7014-T42 or 0553 racks.
Model 7014-T00 rack:
Hardware specifications provide detailed information for your rack, including dimensions, electrical,
power, temperature, environment, and service clearances.
Table 60. Dimensions for rack
Rack
configuration
Width Depth Height Weight
(empty)
Weight
(maximum
configuration)
EIA unit
capacity
Rack with side
covers only
644 mm (25.4
in.)
1016 mm (40.0
in.)
1804 mm (71.0
in.)
244 kg (535 lb) 1387 kg (3060
lb)
1
36 EIA units
Figure 20. Model 0555 and 7014-S25 caster locations
36 Site and hardware planning
